> >Drying Cabinets

Subcategories

  • Drying / Warming Cabinets

    Genlab Drying / Warming Cabinets

    200 Litre Insulated Drying Cabinet
    IWC200
    500 Litre Drying Cabinet
    DC500

    The Genlab range of Drying / Warming Cabinets are suitable for drying a range of items such as glassware, instruments and PCB's. They are also used to aid any general purpose warming applications. Genlab has sold these Drying Cabinets extensively across the globe and they have always proved to be a very popular product.

    Two variants are available which as the standard non-insulated units and insulated units for improved efficiency plus energy and cost savings. A touch screen digital controller is also available as an optional upgrade on the insulated versions.

    Features

    • Temperature range 30 to (ambient+50)ºC
    • 4 sizes 125 to 1000 litres (DC)
    • 4 sizes 100 to 885 litres (IWC)
    • Easy to use thermostatic control
    • Independant overheat thermostat
    • Lockable castors (IWC425 and 885 models)
    • Stainless steel chamber (IWC versions)

    Options

    • Touch screen digital controller with on screen trending (IWC only)
    • Fan assisted circulation (under 250L, standard above 425L)
    • Access ports (25, 50, 75 or 100mm)
    • Traceable calibration to national standards
    • Bespoke stands and stacking kits
    • Wall mounting brackets (100 and 200 versions only)
    • Extractor unit
    • Extended warranty
    • Bespoke solutions available upon request
    • Fan speed control (Between 50 to 100%)

    Design

    The exterior is constructed from sheet steel finished in an easy clean powder coated paint. It is fitted with adjustable shelf runners, removable plated wire grid shelves and ventilation outlets. The insulated range of units give far greater temperature control, allowing greater accuracy during the drying and warming process. The resulting reduction in energy requirements gives a performance saving of over 30% compared to the non-insulated range. Models under 250 litres have sliding, toughened glass doors. the larger models have hinged, toughened glass doors.

    Heating

    Heated by Incoloy sheathed elements which are positioned in the base of the unit. Units above 425 litres have a fan assistance as standard.

    Controls

    Available with two options, thermostatic or touch screen digital interface. thermostatic control comprises of a direct reading thermostat with calibrated scales and tamper proof locks and an indpendant overheat thermostat as standard. They also include a mains switch and heating lamp indicator.

    The upgraded touch screen option offers both accurate temperature control and integral overheat system by using 2 individual Pt100 sensors. Oven trending is displayed for up to 48 hours and cabinet status is shown on the 3.2 in colour screen.

    Specifications

    Non Insulated
    Genlab ref.
    Number
    Capacity
    (litres)
    Internal dims.
    (H x W x D cms)
    External dims.
    (H x W x D cms)
    Shelves
    /positions
    Wattage
    /Voltage
    Weight
    (kg)
    DC125
    125
    43 x 72 x 40
    60 x 74 x 42
    3..5
    500...230
    40
    DC250
    250
    52 x 98 x 48
    66 x 100 x 50
    3..6
    750...230
    55
    DC500
    500
    138 x 58 x 62
    168 x 60 x 65
    3..12
    1750...230
    75
    DC1000
    1000
    138 X 116 X 62
    168 X 118 X 65
    3..12
    2500...230
    130

    Insulated
    Genlab ref.
    Number
    Capacity
    (litres)
    Internal dims.
    (H x W x D cms)
    External dims.
    (H x W x D cms)
    No. of
    Shelves
    Wattage
    /Voltage
    Weight
    (kg)
    IWC100
    100
    40 x 67 x 37
    60 x 74 x 42
    3..5
    500...230
    50
    IWC200
    200
    49 x 93 x 45
    		 66 x 100 x 50
    3..6
    750...230
    75
    IWC425
    425
    		 135 x 53 x 59
    175 x 60 x 65
    3..12
    1750...230
    140
    IWC885
    885
    135 x 112 x 59
    175 x 118 x 65
    3..12
    2500...230
    210

    Ordering

    All units have a powder coated mild steel exterior and the insulated cabinets have 304 Stainless steel interior.

    Where options are required simply add the option code to the original reference.

    E.g. IWC/100 with fan assisted and touch screen controller IWC/100/F/TDIG

    Contact sales for bespoke options.

    Option codes


    Touch Screen Controller - TDIG
    Fan Assisted (less than 250L) - F
    Audible Warning - AWA
    Access Ports - AP
    Traceable Calibration - SPC
    Stands / Stacking Kits - STAND
    Wall Brackets - WALL
    Extractor Systems - EXT
    Extended Warranty - X1
    Fan Speed Controller - FSC

  • New Energy Efficient...

    Genlab E3 Energy Efficient Drying Cabinets

    100 litre Drying Cabinet
    E3DWC100N/TDIG
    885 litre drying cabinet
    E3DWC885/F/TDIG

    Genlab is proud to offer their customers a unique range of sustainable laboratory products and services. E3 is our market leading brand for scientifically developed, cutting edge, sustainable, eco-friendly products. Genlab's new E3 range of glassware drying cabinets are energy efficient, safer and economic to run. Working with the University of Cambridge, we developed units that represent a novel, sustainable solution to glassware drying. The feature our latest touch screen control system, which offer intuitive control and excellent accuracies with bespoke firmware for energy saving control, including adjustable automatic on/off times.

    Features

    • Temperature range 30.0 to 80.0ºC
    • Integral 7 day timer with touch screen digital control
    • Integral energy meter
    • Fully insulated with adjustable vent cover
    • Stainless steel chamber
    • Manual or automatic overheat reset
    • On screen historical trending (48 hours)
    • Lockable castors on the 425 and 885 litre models
    • Low energy consumption - More than 50% lower to traditional cabinets
    • Low heat output - reducing air conditioning cost
    • High accuracy Pt100B duplex sensors <0.8ºC
    • Excellent stabilty <+/- 0.6ºC
    • New - Set point lock feature

    Options

    • Audible warnings
    • Integral Data Logger with reporting firmware
    • Access ports (25, 50, 75 or 100mm)
    • Traceable calibration to national standards
    • Bespoke stands and stacking kits
    • Wall mounting brackets (100 and 200 versions only)
    • Extractor unit
    • Extended warranty
    • Bespoke solutions available upon request
    • Fan speed control (Between 50 to 100%)

    Design

    The exterior is constructed from sheet steel finished in an easy clean powder coated paint. The interior chamber is made from 304 stainless steel and all units have high density insulation. The 100 and 200 litre models have sliding glass doors and the 425 and 885 litre models have double glazed hinged doors.

    Heating

    Heated by Incoloy sheathed elements which are positioned in the lower chamber and covered with 304 stainless steel guard.

    Controls

    The control system comprises of a bespoke touch screen interface that offers both accurate temperature control and integral overheat system by using 2 individual Pt100 sensors. The cabinets automatically turn on and off (up to two times per day) with boost and extended functions available outside of the set times. Oven trending is displayed for up to 48 hours.

    We have created a tutorial video that demonstrates how to use the touch screen control panel of the E3 units. This can be found by clicking here to access the video website page & it is listed as "Chapter 8 Genlab E3 Range Operation"

    Specifications

    Natural Convection
    Genlab ref.
    Number
    Capacity
    (litres)
    Internal dims.
    (H x W x D cms)
    External dims.
    (H x W x D cms)
    Shelves
    /positions
    Wattage
    /Voltage
    Energy Consumption
    kWh/day*
    Weight
    (kg)
    E3DWC100N/TDIG
    100
    40 x 67 x 37
    66 x 72 x 42
    3..4
    500...230
    5.56
    50
    E3DWC200N/TDIG
    200
    49 x 93 x 45
    77 x 100 x 50
    3..4
    750...230
    8.65
    75
    E3DWC425N/TDIG
    425
    135 x 53 x 59
    175 x 60 x 65
    3..12
    1750...230
    13.27
    140

    Fan Assisted
    Genlab ref.
    Number
    Capacity
    (litres)
    Internal dims.
    (H x W x D cms)
    External dims.
    (H x W x D cms)
    No. of
    Shelves
    Wattage
    /Voltage
    Energy Consumption
    kWh/day*
    Weight
    (kg)
    E3DWC100F/TDIG
    100
    40 x 67 x 37
    66 x 72 x 42
    3..4
    500...230
    8.35
    52
    E3DWC200F/TDIG
    200
    49 x 93 x 45
    		 77 x 100 x 50
    3..4
    750...230
    12.97
    77
    E3DWC425F/TDIG
    425
    		 135 x 53 x 59
    175 x 60 x 65
    3..12
    1750...230
    18.32
    142
    E3DWC885F/TDIG
    885
    135 x 111 x 59
    175 x 118 x 65
    3..12
    2500...230
    27.18
    210

    Ordering

    All units have a 304 Stainless steel interior with a touch screen interface as standard.

    Where options are required simply add the option code to the original reference.

    E.g. E3DWC100F/TDIG with extractor unit and wall bracket becomes E3DWC100F/TDIG/EXT/WALL

    Contact sales for bespoke options.

    Option codes


    Audible Warning - AWA
    Access Ports - AP
    Traceable Calibration - SPC
    3 Point Traceable Calibration - 3PC
    Stands - STAND
    Stacking Kits - STACK
    Wall Brackets - WALL
    Extractor Systems - EXT
    Extended Warranty - X1
    Integral Data Logger - ITL
    Fan Speed Controller - FSC

    *All units tested were a set temperature of 75ºC with an empty chamber and the ambient temperature was 22ºC. Energy consumption will differ based on a set temperature and ambient conditions. Fan units are able to remove approximately double the moisture of a convection unit, the time taken to dry a load is therefore halved. As a result the energy used to dry a load is actually lower for a fan unit compared to a natural convection unit.

Drying Cabinets

Drying Cabinets / Warming Cabinets


The GENLAB Drying / Warming Cabinets are suitable for drying a range of items such as glassware and instruments and also any general purpose warming applications.

More >

E3 Drying Cabinets


Forget traditional energy inefficient, costly to run drying cabinets. Genlab’s new E3 range of glassware drying cabinets are unique - first to market, energy efficient, safer and cheaper to run.

More >>

Genlab manufacture a comprehensive range of Drying Cabinets and these units are in use in laboratories, schools and universities worldwide. Typically these particular products are used for drying items such as glassware and instruments. But they can also be used for any general purpose warming application.

All Genlab Drying Cabinets are hand built in the United Kingdom at our factory in Widnes, and  come with Genlab's two year warranty. The internal chamber is made from stainless steel and the external body is made from either powder coated mild steel or stainless steel.

As an additional option, Genlab are also able to supply a stand which keeps the unit at a usable height, but the inbuilt castors allow portability and movement around a laboratory.
